Allen & Heath DX88-P 8×8 96 kHz Remote Control Expander Rack

El precio original era: $4.357.199.El precio actual es: $3.652.799.

For AHM
SQ
Avantis
and dLive Systems

Designed to expand the I/O and remote control capabilities of AHM, SQ, Avantis, and dLive audio mixing systems, the DX88-P from Allen & Heath sports eight mic/line inputs and eight line outputs via standard block connections, allowing you to greatly expand the flexibility of installed audio systems. The DX88-P connects to audio systems or upstream DX Expander units via a single Cat 5e cable, facilitating long cable runs of up to 220′ and sporting convenient plug and play operation—no IP addressing required. A secondary RJ45 port is provided for daisy-chaining to a downstream expander unit for additional remote I/O. Each input channel features phantom power and a -20 dB pad for maximum versatility in live sound reinforcement. An optional rackmount kit is also available, for fitting the unit into a 1 RU slot in a standard audio equipment rack. The DX88-P includes a 12 VDC power supply and a 16 x 3-way contact plug.

Bajo Pedido - Disponible para reserva - Llega en aproximadamente 15 a 20 días hábiles

Valor por transferencia (Precio en Rojo) - Débito/Crédito (6 cuotas s/interés): Precio tachado

6 Cuotas fijas de $773.176

3 Cuotas fijas de $1.412.416

Abonando en efectivo en nuestras oficinas te queda en $3.433.699 o USD2.309.

SKU: BHALAHDX88P Categorías: I/O Expansion Cards, Mesas de mezclas, Mixers, Pro Audio Etiquetas: allen & heath, and dLive Systems, Avantis, Expands I/O & Remote Control Facilities, For AHM, Sq

Descripción

The Rock Store te trae Allen & Heath DX88-P 8×8 96 kHz Remote Control Expander Rack

Sus características técnicas principales son:

Designed to expand the I/O and remote control capabilities of AHM, SQ, Avantis, and dLive audio mixing systems, the DX88-P from Allen & Heath sports eight mic/line inputs and eight line outputs via standard block connections, allowing you to greatly expand the flexibility of installed audio systems. The DX88-P connects to audio systems or upstream DX Expander units via a single Cat 5e cable, facilitating long cable runs of up to 220′ and sporting convenient plug and play operation—no IP addressing required.

A secondary RJ45 port is provided for daisy-chaining to a downstream expander unit for additional remote I/O. Each input channel features phantom power and a -20 dB pad for maximum versatility in live sound reinforcement. An optional rackmount kit is also available, for fitting the unit into a 1 RU slot in a standard audio equipment rack. The DX88-P includes a 12 VDC power supply and a 16 x 3-way contact plug.

Aviso: Las especificaciones y disponibilidad pueden cambiar sin previo aviso.

Información adicional

Peso	2,9801 kg
Dimensiones	38,1 × 37,592 × 13,208 cm
Peso	3.33 lb / 1.51 kg
Corriente de funcionamiento	3.3 A
Color	Negro
Impedancia de entrada	>4 Kilohms (Pad Out) >10 Kilohms (Pad In)
Operating Conditions	32 to 104°F / 0 to 40°C
Nivel máximo de salida	+21 dBu
Montaje	Side: 1x Optional Rackmount
Compatibilidad	– Allen & Heath – SQ Digital Mixers – / – AHM Audio Matrix Processors – / – Avantis Digital Mixers – / – dLive Digital Mixers
Nivel máximo de entrada	+30 dBu (Pad In)
Impedancia de salida	<75 Ohms
Ganar	+5 to +60 dB (1 dB Steps)
A	-127 dB (With 150 Ohm Source)
Sensibilidad de entrada	-60 to +15 dBu
Almohadilla	-20 dB
E/S de audio	8x Block 3-Pin Line/Mic Input 8x Block 3-Pin Line Output
Fuente de energía	AC Adapter with Power Brick (Included)
Alimentación de entrada CC	12 VDC at 3.3 A
Consumo de energía	39.6 W
Material de construcción	Metal
Dimensiones	8.5 x 7.7 x 1.7″ / 21.6 x 19.6 x 4.3 cm
