Blackmagic Design 2110 IP Converter 4x12G PWR

Descripción

The Rock Store te trae Blackmagic Design 2110 IP Converter 4x12G PWR

Sus características técnicas principales son:

Converter
Expands 12G-SDI broadcast accessories with SMPTE 2110 IP video
Equipped with four independent bidirectional 12G SDI to SMPTE 2110 IP video converters and uses RJ-45 10G Ethernet ports, which can also supply power
Supports Ultra HD standards up to 2160p/60
Front panel with LCD
Computer interface: 1 USB-C 3.0 port for configuration and product software updates
Audio: Loudspeakers on the front panel with on/off button and 1 x 6.35 mm headphone jack
Controls: Front panel with 12 buttons
2.2-inch colour LCD and rotary control
Compatible operating systems: Mac 13.0 Ventura, Mac 14.0 Sonoma or higher / Windows 10 and 11
Power supply: 2 integrated AC power supplies for 100–240 50/60 Hz with IEC-C14 mains power socket
Power consumption: Max. 410 W
Dimensions: 482 x 44 x 234 mm
Weight: 3.73 kg
Connections:
Total SDI inputs: 5
SDI video inputs: 4
Inputs for the SDI main programme: 1
Total SDI outputs: 5
SDI video outputs: 4
Outputs for the SDI main programme: 1 loop-through output
SDI rates: 270 Mbit, 1.5 G, 3 G, 6 G, 12 G
Inputs for SMPTE ST-2110 IP video: Four 10G Ethernet ports
Outputs for SMPTE ST-2110 IP video: Four 10G Ethernet ports
Analogue audio outputs: 1 x 6.35 mm headphone jack
SDI audio inputs: 16 embedded audio channels on the SDI input
SDI audio outputs: 16 embedded audio channels on the SDI loop-through output
Inputs for SMPTE ST-2110 IP audio: 16 embedded audio channels in ST-2110 IP video inputs via 10G Ethernet
Outputs for SMPTE ST-2110 IP audio: 16 embedded audio channels in ST-2110 IP video inputs via 10G Ethernet
Multi-rate support: automatic detection of SD, HD, Ultra HD and 4K
Reclocking: Yes
Ethernet: 4 x 10 Gbit/s PoE++ RJ45 connectors support 10/100/1000/10GBase-T for SMPTE 2110 IP video input and output (PoE++ is used exclusively to supply power to connected PoE devices) / 1 x 10 Gbit/s RJ45 connector supports 10/100/1000GBase-T for SMPTE for configuration and product software updates
Converter
* Expands 12G-SDI broadcast accessories with SMPTE 2110 IP video Equipped with four independent bidirectional 12G SDI to SMPTE 2110 IP video converters and uses RJ-45 10G Ethernet ports, which can also supply power Supports Ultra HD standards up to 2160p/60 Front panel with LCD Computer interface: 1 USB-C 3.0 port for configuration and product software updates Audio: Loudspeakers on the front panel with on/off button and 1 x 6.35 mm headphone jack Controls: Front panel with 12 buttons 2.2-inch colour LCD and rotary control Compatible operating systems: Mac 13.0 Ventura, Mac 14.0 Sonoma or higher / Windows 10 and 11 Power supply: 2 integrated AC power supplies for 100–240 50/60 Hz with IEC-C14 mains power socket Power consumption: Max. 410 W Dimensions: 482 x 44 x 234 mm Weight: 3.73 kg Connections: Total SDI inputs: 5 SDI video inputs: 4 Inputs for the SDI main programme: 1 Total SDI outputs: 5 SDI video outputs: 4 Outputs for the SDI main programme: 1 loop-through output SDI rates: 270 Mbit, 1.5 G, 3 G, 6 G, 12 G Inputs for SMPTE ST-2110 IP video: Four 10G Ethernet ports Outputs for SMPTE ST-2110 IP video: Four 10G Ethernet ports Analogue audio outputs: 1 x 6.35 mm headphone jack SDI audio inputs: 16 embedded audio channels on the SDI input SDI audio outputs: 16 embedded audio channels on the SDI loop-through output Inputs for SMPTE ST-2110 IP audio: 16 embedded audio channels in ST-2110 IP video inputs via 10G Ethernet Outputs for SMPTE ST-2110 IP audio: 16 embedded audio channels in ST-2110 IP video inputs via 10G Ethernet Multi-rate support: automatic detection of SD, HD, Ultra HD and 4K Reclocking: Yes Ethernet: 4 x 10 Gbit/s PoE++ RJ45 connectors support 10/100/1000/10GBase-T for SMPTE 2110 IP video input and output (PoE++ is used exclusively to supply power to connected PoE devices) / 1 x 10 Gbit/s RJ45 connector supports 10/100/1000GBase-T for SMPTE for configuration and product software updates
